Product Introduction
In sand and gravel aggregate and grinding systems, it can generally increase the output by 30%-40% and reduce the total energy by 20%-30%. It can finely crush materials of various hardness in mineral processing, chemical industry, refractory materials, stone, building materials and other industries.
Product Advantages
01.
It adopts heavy-duty thickened roller skin, which is wear-resistant and impact-resistant, and cooperates with the automatic lubrication device to greatly extend the life of the parts;
02.
Automated control system reduces investment and usage costs;
03.
Smooth operation and equipped with overload protection system.
Application Scope
Hydraulic roller mills can finely crush materials of various hardness in industries such as mineral processing, chemical industry, refractory materials, stone materials, and building materials.
Main Technical Specifications
| Model | Max Feeding Size（mm） | Discharge Processing Capacity（t/h） | ||
| 5mm | 10mm | 20mm | ||
| 2PGY1008 | ≤40 | 8-33 | 24-98 | 32-130 |
| 2PGY1210 | ≤60 | 12-50 | 37-148 | 49-197 |
| 2PGY1510 | ≤80 | 15-60 | 46-185 | 60-245 |
| 2PGY1810 | ≤100 | 18-75 | 55-220 | 73-295 |
| 2PGY2012 | ≤120 | 25-100 | 73-295 | 97-390 |
