Product Introduction
In this process, the granulated material is placed in an inclined and rotating disk, and is subject to the combined action of gravity, centrifugal force and friction, causing the material to roll and rub. With the appropriate addition of moisture, the material gradually forms a cue ball.
The fine-grained material rolls on the surface of the wet cue ball, causing the cue ball to gradually increase in size and gain a certain strength. Pellets of different sizes will automatically run along different tracks in the disc, and finally the finished pellets that meet the requirements are discharged from the disc. This pelletizing process can transform originally scattered fine-grained materials into regular spherical particles to meet the requirements of subsequent production processes.
Product Advantages
01.
Adopting large-diameter slewing bearings and plane supports to ensure that the pelletizing disc is stable and vibration-free during operation, thus ensuring high pelletizing quality.
02.
The ball making output is large. The output of qualified balls of the 6-meter pellet making machine is maintained at 60-90 tons per hour, and the output of the 7.5-meter pellet making machine is maintained at 120-160 tons per hour.
03.
Low energy consumption, the energy consumption per ton of balls is 0.7-0.8 of the traditional pelletizing machine, allowing enterprises to save energy and reduce consumption during the production process, and obtain considerable economic and social benefits.
04.
Compared with traditional pelletizing machines, the amount of maintenance is greatly reduced and there are fewer failures.
05.
Adopting a closed internal gear transmission system, the transmission gear is isolated from external dust, effectively protecting the tooth surface from wear and tear due to dust and contamination, reducing the failure rate, extending the service life of the gear, and ensuring the continuous and stable operation of the equipment.
06.
The body of the pelletizing disc adopts flat support to make it run smoothly and without vibration.
07.
The center distance and clearance of the large and small gears are guaranteed by machining, so the transmission accuracy is high.
Application Scope
The disc granulator is suitable for materials such as phosphogypsum, iron powder, steel balls, pellet powder, etc.
Main Technical Specifications
Disk balling machine technical parameter table (Large Type)
| Model | PQ45 | PQ50 | PQ60 | PQ70 | PQ75 |
| Diameter（mm） | 4500 | 5000 | 6000 | 7000 | 7500 |
| Height（mm） | 550 | 550 | 650 | 650 | 650 |
| Inclination（°） | 45-55 | 43-53 | 43-53 | 43-53 | 43-53 |
| Speed（r/min） | 1~9 | 6~8.5 | 6~8.5 | 5.1~7.9 | 5.1~7.9 |
| Main Motor Power/kw | 45 | 55-75 | 90-110 | 132-185 | 160-200 |
| Scraper Motor Power/kw | 4×2 | 5.5×2 | 5.5×2 | 5.5×3 | 5.5×3 |
PQT（Special fir Pellets）Technical Specifications
| Model | Diameter（mm） | Height（mm） | Inclination（°） | Speed（r/min） | Main Motor Power（kW） | Scraper Motor Power（kW） |
| PQ50 | 5000 | 600 | 43~53° | 6~9 | 75 | 5.5×2 |
| PQ55 | 5500 | 650 | 43~53° | 5.7~8.5 | 90 | 5.5×2 |
| PQ60 | 6000 | 650 | 43~53° | 5.7~8.5 | 110 | 5.5×2 |
| PQ70 | 7000 | 650 | 43~53° | 5.1~7.9 | 185 | 5.5×3 |
| PQ75 | 7500 | 650 | 43~53° | 5.1~7.9 | 200 | 5.5×3 |
