Product Introduction
Through years of production practice, it is proved that this vibrating screen has large processing capacity, reasonable technical parameters, high structural strength and rigidity, and a high degree of generalization and standardization.
Product Advantages
01.
Large processing capacity, high structural strength, sturdy and durable, and easy maintenance.
02.
Low energy consumption, low noise and long screen service life.
03.
High screening precision and high screening efficiency.
04.
Stable operation, safe and reliable.
Application Scope
ZK series linear vibrating screens are widely used in coal, mining, metallurgy, building materials, light industry, environmental protection, transportation and other industries for dry and wet screening, classification or dehydration, desliming, demediation, etc. of various medium and fine materials.
Main Technical Specifications
| Model | Screen | Feeding Particle Size (mm) | Motor Power(kw) | Capacity (t/h) | |
| Area (m2) | Tilt Angle | ||||
| ZK1022 | 2.25 | -5~5 | <250 | 3*2 | 4.5-90 |
| ZK1230 | 3.6 | -5~5 | <250 | 4*2 | 7.2-144 |
| ZK1237 | 4.5 | -5~5 | <250 | 5.5*2 | 9-180 |
| ZK1437 | 5.25 | -5~5 | <250 | 5.5*2 | 12-250 |
| ZK1445 | 6.3 | -5~5 | <250 | 7.5*2 | 12.6-252 |
| ZK1637 | 6 | -5~5 | <250 | 5.5*2 | 12-240 |
| ZK1645 | 7.32 | -5~5 | <250 | 11*2 | 95-280 |
| ZK1837 | 6.75 | -5~5 | <250 | 11*2 | 90-270 |
| ZK1845 | 8.1 | -5~5 | <250 | 11*2 | 16.2-234 |
| ZK1852 | 9.45 | -5~5 | <250 | 11*2 | 18.9-378 |
| ZK2045 | 9 | -5~5 | <250 | 11*2 | 16.2-234 |
| ZK2052 | 10.5 | -5~5 | <250 | 11*2 | 21-420 |
| ZK2060 | 12 | -5~5 | <250 | 15*2 | 24-480 |
| ZK2445 | 10.8 | -5~5 | <250 | 15*2 | 21.6-432 |
| ZK2452 | 12.6 | -5~5 | <250 | 15*2 | 25.2-504 |
| ZK2460 | 14.4 | -5~5 | <250 | 15*2 | 28.8-576 |
| ZK3045 | 13.5 | -5~5 | <250 | 15*2 | 27-540 |
| ZK3052 | 15.75 | -5~5 | <250 | 22*2 | 31.4-628 |
| ZK3060 | 18 | -5~5 | <250 | 22*2 | 17.5-525 |
| ZK3645 | 16.2 | -5~5 | <250 | 22*2 | 37.8-756 |
| ZK3652 | 18.9 | -5~5 | <250 | 22*2 | 43.2-864 |
| ZK3660 | 21.6 | -5~5 | <250 | 22*2 | 43.2-864 |
| ZK3675 | 27 | -5~5 | <250 | 30*2 | 54-1080 |
| 2ZK1022 | 2.25 | -5~5 | <250 | 4*2 | 4.5-90 |
| 2ZK1230 | 3.6 | -5~5 | <250 | 5.5*2 | 7.2-144 |
| 2ZK1237 | 4.5 | -5~5 | <250 | 7.5*2 | 9-180 |
| 2ZK1437 | 5.25 | -5~5 | <250 | 7.5*2 | 12-250 |
| 2ZK1445 | 6.3 | -5~5 | <250 | 15*2 | 12.6-252 |
| 2ZK1637 | 6 | -5~5 | <250 | 15*2 | 12-240 |
| 2ZK1645 | 7.32 | -5~5 | <250 | 15*2 | 95-280 |
| 2ZK1837 | 6.75 | -5~5 | <250 | 15*2 | 90-270 |
| 2ZK1845 | 8.1 | -5~5 | <250 | 15*2 | 16.2-234 |
| 2ZK1852 | 9.45 | -5~5 | <250 | 15*2 | 18.9-324 |
| 2ZK2045 | 9 | -5~5 | <250 | 15*2 | 16.2-234 |
| 2ZK2052 | 10.5 | -5~5 | <250 | 22*2 | 21-420 |
| 2ZK2060 | 12 | -5~5 | <250 | 22*2 | 24-480 |
| 2ZK2445 | 10.8 | -5~5 | <250 | 22*2 | 21.6-432 |
| 2ZK2452 | 12.6 | -5~5 | <250 | 22*2 | 25.2-504 |
| 2ZK2460 | 14.4 | -5~5 | <250 | 22*2 | 28.8-576 |
| 2ZK3045 | 13.5 | -5~5 | <250 | 30*2 | 27-540 |
| 2ZK3052 | 15.75 | -5~5 | <250 | 37*2 | 31.4-628 |
| 2ZK3060 | 18 | -5~5 | <250 | 37*2 | 17.5-525 |
| 2ZK3645 | 16.2 | -5~5 | <250 | 45*2 | 37.8-756 |
| ZK3652 | 18.9 | -5~5 | <250 | 45*2 | 43.2-864 |
| ZK3660 | 21.6 | -5~5 | <250 | 45*2 | 43.2-864 |
